An AutoCAD plugin toolkit designed to significantly enhance the drawing efficiency and accuracy for structural engineers.
Overview
The Wooden Fish Structure Toolbox integrates benchmark and butcher structure toolkits, simplifying structural drawing tasks for users.
Update History
July 2, 2012
This version is based on software 2.0, now including the LiZheng Structure 6.5 calculation tool. It fully integrates the internal program ZCTOOL-V2.4 from FoolEngineer and benchmark architectural design firm.
Most less useful tools and plugins have been removed, including the e-book query feature, focusing solely on standardized and customized services.
Note: Access to this query function requires user registration.
July 3, 2012
Support for the MSTEEL function has been removed as it was deemed ineffective.
A new feature to draw welding symbols for steel structures has been added.
July 11, 2012
Resolved conflicts with Tianzheng Building software that caused lock warnings.
Added numerous new functions for structural drawing (note: the scaling feature is still under development).
Introduced a menu collapse feature.
Removed unnecessary plugins, improving loading times and overall speed.
Added a plugin to display graphic information with mouse placement from versions 05 to 08.
Included a structural image library feature.
To use this toolkit, AutoCAD must be installed. The editor recommends the AutoCAD 2004 mini version.
Download link: __AI_SBT-URL. 0__
