BIM Q&A: Understanding BIM Levels and Exploring Level 3 Applications in Prefabricated Buildings

Finally, let’s explore the third-level application of BIM in prefabricated buildings:

Design Phase Objectives

Model: Develop engineering survey models along with comprehensive project-wide professional design models.

Application: Utilize 3D visualization, performance analysis, material and component quantity statistics, design conflict detection, and generate 2D construction drawings.

Management: Implement BIM-based design management systems.

Application Requirements:

• Model: Achieve a model detail level of LOD300.
• Application: Conduct thorough site analysis, optimize design schemes, support collaborative design, perform clash detection and performance analysis, estimate investment, standardize component design, and produce 2D drawings.
• Management: Establish BIM-based design management systems and utilize BIM design management platforms.

Production Phase Objectives

Model: Create detailed design models for precast concrete (PC) components and production models for main PC components.

Application: Use detailed PC component models for drawing creation, quantity takeoffs, and auxiliary component template design.

Management: Leverage BIM to assist in managing PC component production.

Application Requirements:

• Model: Achieve a model detail level of LOD400.
• Application: Complete detailed component design, quantity statistics, production planning and management, transportation logistics, and integrate production information.
• Management: Develop BIM-based production management systems and adopt BIM production management platforms.

Construction Phase Objectives

Model: Develop detailed design models covering architecture, structure, and MEP (mechanical, electrical, and plumbing) disciplines. Create construction models for critical nodes, site layout, scaffolding, and construction equipment.

Application: Perform construction simulations and walkthroughs, floor inspections, clash detection, quantity takeoffs, quality management, and real-time supervision.

Management: Establish BIM-based management systems and deploy BIM management platforms.

Application Requirements:

• Model: Maintain model detail level at LOD400.
• Application: Implement seven key applications including construction plan optimization, progress simulation, on-site coordination, equipment and material management, quality and safety control, contract management, and project completion acceptance.
• Management: Set up a BIM-based project management system and utilize BIM construction management platforms.

Operation and Maintenance Phase

Model: Receive and review as-built models to establish operation and maintenance models.

Application: Use these models for facility querying, management, and monitoring of critical equipment and spaces.

Management: Build BIM-based management systems for ongoing operations.

Application Requirements:

• Model: Reach a model detail level of LOD500.
• Application: Enable virtual simulation walkthroughs, integrate on-site 3D data collection, manage equipment and facility maintenance, oversee construction project safety, emergency response, and sub-item renovations.
• Management: Establish BIM-based operation and maintenance management platforms.
