From the perspective of design firms, transitioning from traditional CAD-based workflows to BIM-based 3D design typically involves three key stages:
(1) Mastering the Software
Mastering the software means becoming proficient in the entire process from modeling to drawing—whether using BIM for forward design or for pipeline synthesis. Modeling is the fundamental foundation for all design activities. Only by mastering modeling techniques can the resulting models be effectively utilized to create practical value in subsequent workflows.
(2) Expressing “3D-to-2D”
The term “3D-to-2D” refers to the ability to convert three-dimensional model information into two-dimensional drawings. At this stage, BIM team members must produce numerous 2D drawings that align with local drafting conventions, continuously optimizing 2D plans in real time. This requires a solid understanding of BIM modeling, family creation methods, and 2D representation techniques of BIM families, along with the ability to apply these skills practically.
(3) Using BIM 3D Models for Multi-Disciplinary Design Coordination
In this phase, designers use BIM 3D information models to coordinate design across various disciplines. Beyond the skills gained in the previous stages, they must be capable of leveraging information models for mutual reference and communication.
This stage demands organized, multi-disciplinary use of models to facilitate interdisciplinary communication and coordination. Examples include using models developed in later design stages for comprehensive pipeline layout, spatial optimization, and adjustments to pipeline openings. On-site research shows that while most design firms successfully complete the first stage, many face challenges in the second. Only a few firms reach the third stage, and even then, usually in limited specialties.
The bottlenecks encountered during the second stage typically fall into two categories: overall application issues and localized application problems. Overall application challenges are common to most design firms today and cannot be resolved by individuals or departments alone; they require industry-wide solutions. Localized problems, on the other hand, are urgent and complex issues that firms must tackle immediately through sustained effort.
Key overall application challenges in BIM forward design include responsibilities for documentation, technical standards and specifications, cost concerns, drawing management, archiving technical documents, software limitations, and issues related to application depth and deliverables. The main local challenges involve improving modeling efficiency, model calculations, review processes, and annotation accuracy.
These challenges primarily affect the design industry. BIM forward design struggles to fully align with the “high turnover” model commonly used by real estate companies, and faces practical difficulties during project implementation. Traditional 2D CAD drawings involve creating images on a computer and then manually processing information correlations, which can sometimes gloss over imprecise content—resulting in faster workflows and higher turnover.
In contrast, BIM forward design requires extensive data input early on through computer interaction to automatically process information and generate benefits later in the project. This approach demands significant upfront time and investment, contrasting sharply with traditional design workflows and pace. As a result, failing to meet project deadlines or client timeframes is a frequent problem, causing many BIM forward design projects to be abandoned when critical deadlines are missed.
