An essential step in applying BIM technology to construction projects is to establish a BIM model that adheres to the following key principles:
1. Consistency Principle: The BIM model must align with the CAD drawings and closely follow the detailed design developments and updates at every project stage. The model’s internal data should accurately reflect relevant information such as names, materials, and model specifications of the objects used.
2. Rationality Principle: The model should realistically represent the construction, establishing a layered structure based on elevation. For example, it is strictly prohibited for a support column to extend from the foundation’s bottom layer all the way to the top layer. Modeling should be based on the actual start and end elevations.
3. Accuracy Principle: The positions and coordinates of key points—such as the main transverse points and start/end points of major components like beams and walls—must be precisely set according to the actual design conditions. This avoids issues like beams or walls intersecting or overlapping with columns. Additionally, automatic overlapping models for slabs, columns, and beams should be created promptly according to their real usage.
Modeling Process:
1. Template Setup: Establish the project base point, load frequently used families, set project units, define the model style, and determine other parameters referencing the project overview and construction design drawings.
2. Model Creation: Build the elevation and grid system based on the drawings, then develop models for structural components, site elements, and large-scale mechanical parts.
3. Model Review: Verify the completeness of structural components and the accuracy of component information, ensuring compliance with the project’s BIM objectives.
4. Information Enrichment: Add essential data attributes and metadata to the model for comprehensive documentation.
That concludes the overview of the principles and process for creating BIM models in construction projects. I hope you find this information helpful!
