Compared to current construction projects, the application of BIM technology in bridge engineering remains somewhat limited in both scope and depth. Bridge engineering itself possesses unique characteristics that differ from general construction engineering, leading to different focuses in BIM technology utilization. Below are the key features of BIM-based bridge engineering design when compared to construction engineering:
(1) Logical Structure: Bridge structural design is highly logical and well-suited for parametric design. The main bridge structure is arranged along the road alignment, which acts as a reference line, while the cross-sectional shape remains relatively fixed along the baseline. Components are regularly arranged in space and connected through lines following specific topological relationships. This setup facilitates establishing parameter relationships between various elements within the BIM platform, allowing structural models of the bridge to be efficiently modified by adjusting these parameters, thus enhancing the design scheme.
The ability to modify lines highlights the superior applicability of parameterization in bridge structures.
(2) Load Considerations: Beyond the structure’s self-weight, ancillary equipment, and dead loads such as fill soil, bridges must also withstand dynamic loads from vehicles and trains, in addition to wind and earthquake forces. These dynamic loads often have significant magnitudes, demanding that BIM platforms provide robust structural stress analysis capabilities or data interfaces that integrate with specialized analysis software.
(3) Ancillary Facilities: Bridge engineering involves relatively simple ancillary facilities, covering fewer disciplines (limited to ancillary components). Therefore, the requirements for BIM software features like clash detection are lower compared to other construction fields.
(4) Engineering Scope: Bridge projects typically cover large areas and complex surrounding environments. For instance, municipal overpasses involve extensive and intricate design work. Traditional 2D design methods often convey abstract representations, making information communication challenging and resulting in poor coordination among upstream and downstream disciplines. When issues arise, verification and modification become difficult, sometimes necessitating a complete redesign. Consequently, BIM platforms tasked with bridge design require enhanced capabilities to carry and transmit detailed information, establish strong relationships between various elements, and support collaborative modifications throughout the design process.
