Many engineers recognize that BIM technology can reduce costs, yet few can clearly explain how this is achieved. Currently, the role of BIM in cost control can be divided into two main aspects: firstly, computer-aided cost savings; secondly, cost management supported by data capabilities.
Computer-aided cost savings involve resolving drawing issues, collision detection, net height verification, and site layout planning. Traditionally, drawing reviews mainly focused on major issues identified by construction teams. Minor elevation and positional errors often went unnoticed until construction was underway, even by experienced workers. With BIM technology, the time required to address drawing problems is significantly reduced. Once a 3D model is created, it becomes clear and intuitive which issues stem from the drawings themselves. This model acts as a virtual pre-construction phase.
Collision detection goes beyond single-discipline reviews, involving a comprehensive analysis across multiple specialties. This process often reveals clashes between structural elements and mechanical, electrical, or plumbing installations, as well as conflicts within these systems. Additionally, net height verification is crucial; discovering insufficient clearance after construction leads to costly rework, such as chiseling or reconstruction.
Effective site layout and planning further minimize secondary handling and safety risks, serving as an important cost control measure. Overall, using BIM technology to proactively identify and resolve issues reduces unnecessary rework and waste, resulting in significant cost savings. By simulating construction and performing collision checks, design problems can be detected early and addressed promptly. This approach lowers construction complexity, minimizes engineering changes, controls costs, and ultimately saves money.
The second aspect, dynamic cost monitoring through data capabilities, leverages the information embedded in BIM models for statistical analysis and breakdown. This allows real-time tracking of quantities and costs for any project at any stage, enabling comparisons between progress schedules and cost plans.
For example, a project might aim for a monthly output value of 10 million yuan, with actual costs of 8 million yuan and a profit of 2 million yuan. However, understanding which subprojects are profitable or causing losses can be difficult. BIM technology extracts costs linked to specific components and processes, making it possible to conduct detailed comparisons and dynamically monitor expenses.
After reviewing these points, readers should have a clearer understanding of how BIM supports cost control. Although BIM technology is still developing and its adoption across the industry remains limited, its future potential promises significant improvements and surprises.
