BIM technology can be combined with various other technologies to expand its application scope, as outlined below:
1. BIM + Cloud Computing
Integrating BIM with cloud computing leverages the strengths of cloud technology to transform BIM applications into cloud-based services. With the powerful computing capabilities of the cloud, complex calculations, modeling tasks, and large-scale data storage can be handled remotely. Users only need devices capable of querying and receiving results, allowing even simple, portable devices to complete complex operations. This enables sharing and access anytime, anywhere.
Cloud services can be accessed via mobile devices on construction sites, allowing management teams to monitor and control on-site activities remotely. For example, gas companies use BIM combined with big data and cloud computing to predict downstream gas usage. Typically, urban gas companies pre-agree with suppliers on daily natural gas intake volumes. If gas consumption exceeds the agreed amount, the incremental gas is charged at a higher rate, while unused gas results in lower reimbursement. This system helps reduce losses by accurately forecasting gas volume usage.
2. BIM + Internet of Things (IoT)
The integration of BIM and IoT enables enhanced information management throughout the construction process. IoT devices provide capabilities such as data recognition, collection, transmission, monitoring, and interaction. Positioning technology tracks and alerts against non-compliant operations. Monitoring parameters like temperature, humidity, gas concentration, and composition in pipelines offers real-time safety feedback, helping minimize accidents.
This combination facilitates real-time monitoring and rapid response during construction. By merging virtual BIM data with physical hardware environments, it adds significant value across construction, building, and operational stages. For instance, a large-scale precast concrete project in Pujiang, Shanghai, employs BIM and IoT technologies to achieve intelligent and dynamic project management.
3. BIM + Intelligent Total Station
Measurement is a vital aspect of project management and cost control. Integrating BIM with intelligent total station technology combines software and hardware by introducing BIM models directly to the construction site. Using 3D coordinate data from the BIM model, the intelligent total station performs measurements that are then compared with actual survey data to detect deviations and enable timely adjustments.
An example is the Shenzhen rail transit project, which utilizes BIM combined with intelligent total stations to ensure precise control and seamless project integration.
4. BIM + Geographic Information System (GIS)
The combination of BIM and GIS enhances management capabilities for large-scale, long-term regional projects. It serves as an integrated platform for managing spatial geographic data across entire cities, proving invaluable for optimizing pipeline design, urban planning, environmental analysis, fire prevention, and disaster control.
This integration significantly improves the quality of urban planning and construction. Large and complex projects often pair this integration with cloud computing, moving towards network-based services that further strengthen cross-regional collaboration.
5. BIM + 3D Scanning
The integration of BIM with 3D scanning technology is increasingly used in construction for quality inspection, engineering statistics, and steel structure pre-assembly. 3D scanning quickly and accurately captures detailed spatial structures, offering ease of use and high precision.
The digital documents generated assist subsequent operation and maintenance management. This technology enables fast quality detection, reduces rework, accelerates modeling, and resolves issues that traditional methods cannot address. For example, the Shanghai Center Building project uses large-space 3D laser scanning to provide accurate construction data, enhancing both convenience and efficiency.
6. BIM + Virtual Reality (VR)
Combining BIM with virtual reality technology enhances simulation realism. Unlike traditional 2D or 3D models, VR presents project information in a highly immersive manner. By incorporating real environmental parameters, VR creates realistic sensory experiences including visual, auditory, tactile, and even stress feedback, representing a major advancement in technical visualization.
This integration supports the entire project lifecycle, enabling visual information integration and sharing across different phases and disciplines. Within virtual reality environments, multiple projects can be managed dynamically, allowing users to switch between construction projects in real time, quickly identify design flaws or construction inconsistencies, and improve overall accuracy.
