Automatic Rotating Fabric Machine.rfa
Resource Screenshot
The concrete laying machine features a steel structure support, combined with longitudinal (large) and transverse (small) running mechanisms. It includes a concrete storage hopper, which houses a screw conveyor, gate device, and flipping device, along with safety features, a hydraulic system, and an electrical control system.
Resource Specifications
Product Parameters
Materials and Finishes
Platform material, pump tube material, counterweight support material, column body material, control room material, pipe tail material, cantilever material, escalator material, fixed counterweight material, counterweight material, platform beam material, small ladder material, model text material, platform enclosure material, railing material, rotation transmission part material, cantilever edge material, machine room enclosure material.
Dimensions
Column height: 7000mm
Platform width: 2000mm
Escalator step distance: 160mm
Handrail height: 1100mm
Cantilever height: 9800mm
Cantilever length: 7000mm
Control room width: 1000mm
Control room bottom length: 1200mm
Platform thickness: 80mm
Column body downward extension length: 0mm
Railing height: 1200mm
Pump pipe tail length: 2000mm
Rotation transmission part array radius: 600mm
Column cap radius: 900mm
Control roof length: 1500mm
Rotation angle: 90°
Column cap thickness: 100mm
Platform length: 3000mm
Support width: 2000mm
Platform edge thickness: 180mm
Column body length: 1000mm
Platform opening width: 1000mm
Model text depth: 20mm
Platform height: 4000mm
Cantilever extension distance: 500mm
Support length: 2000mm
Rotation transmission part radius: 300mm
Column body width: 1000mm
Pump pipe downward extension distance: 2900mm
Control room height: 1200mm
Platform opening length: 1500mm
Identification Data
Manufacturer, Part Code, URL, Description, Model Annotation, Type, Image, Cost, Annotation
Additional Data
Number of escalator steps (over 10): 30
